U Drains
U Drain Heavy (T25)
Our Heavy Duty (T-25) U Drains are engineered for locations subject to heavy vehicular and industrial loading, with thicker walls and base than the standard Light Duty range, while retaining the same leak-proof jointed design.
Key Features
- Heavy Duty (T-25) load class, rated for 5T and 10T wheel/axle loads
- Available in six standard sizes from 300x300mm to 1200x1200mm
- Precast in M40/M50 grade concrete for high strength and durability
- Grooved joint detail for a secure, mortar-filled connection between units
- Cast-in lifting barrel for safe, controlled handling and installation
- Standard cover slabs available, with or without drainage holes
Advantages
- Higher load rating than Light Duty (T-6) for vehicular and industrial areas
- Factory-controlled precast quality, consistent from unit to unit
- Faster installation than cast-in-situ drainage channels
- Configurable dimensions via the Engineering Product Studio before ordering
Specifications
Load Class
Heavy Duty (T-25)
Wheel/Axle Load Capacity
5T and 10T
Concrete Grade
M40/M50
Standard Length
2000mm
Available Sizes (a x c)
300x300 to 1200x1200mm
Joint Type
Grooved joint, mortar filled
Applications
- Storm water drainage on roads and highways
- Industrial and warehouse yard drainage
- Power and telecommunication cable ducting
- Areas subject to heavy vehicle traffic
Installation Guide
1
Site Preparation
Ensure a level, compacted base or bedding as per the layout drawing before the unit arrives.
2
Positioning
Units are lifted and positioned using appropriate lifting equipment under our team's guidance.
3
Alignment & Jointing
Units are aligned to the design grade and joints are sealed or grouted as specified.
4
Final Check
A final inspection confirms alignment, finish and stability before handover.
Our installation team is available to assist on site for this product — request installation support.
